Description Complete Product DetailsComplete Product Details Exclusive Features Heavy-Duty Galvanized Finish – All Steel Frame Roll Up Mechanical Door On Both Ends Wind Brace Support on Each Corner Double Cover Tensioning System Complete Anchoring System Included 12 oz. CPAI-84 Fabric Cover and Doors Assembles in 8 Hrs Arch spacing every 48 inches (4 foot spacing’s) Pipe Size Click Here for Fabric Details Click Here for Steel Tubing Details Standard Specifications Product Size 30’ Wide x 40’ Long x 15’ High Arches Seven (7) on 68″ spacing 2 3/8″ Diameter Frame members Standard End Door Size 12′ Wide x 12’6″ High at edge mechanical roll up design Available Colors Outer Colors: White All Interiors: White Only Shipping Weight 2200 lbs. in Two (2) Crates shipped via motor freight Pallet Dimensions 40″ x 115″ x 47″ Box Dimensions Box 1: 115″ Lx29″ Wx29″ High Box 2: 115″ Lx29″ Wx24″ High Main Cover UV protected 24 mil, fabric backed poly. 12oz. weight Fire Retardant Standard Main Cover & Doors meet CPAI -84 Section 5 Anchors Fourteen (14) 36″ Anchors & Fourteen (14) Augers Included Stock Number 30x40x15- TR304015RWHD-4 Product Documentation the product spec sheet the single door assembly manual the two door assembly manual
