Description Complete Product DetailsAdditional Product AccessoriesComplete Product Details Exclusive Features Heavy Duty Galvanized Finish on All Steel Frame Components for Maximum Strength & Long Life. Easy Bolt Together Design –All Pre-drilled & Cut Wind Brace Support on Both Sides Two(2) Double Zipper Doors with Bottom Pockets One (1) complete Roll-up Door Kit Protective Plastic Tube End Caps – All Open Ends Standard Thread Plated Hardware Kit with Retaining Nuts & Protective SS Washers Quick Assembly Wrench included Heavy Duty Poly Rope for Main Cover Tie Down Heavy Duty Grommets on Cover & Doors Twenty-Two (22) permanent anchors included Twelve(12) Box Shipment Average install time – 8 to 10 hours Pipe Size Click Here for Fabric Details Click Here for Steel Tubing Details Standard Specifications Nominal Size 14’ Wide x 42’ Long x 17’ High Arches Eleven (11) on 48” Spacing 2-3/8” diameter frame members Standard End Door Size12’ Wide x 11’8″ High at edge double zipper door each end Available ColorsOuter Colors: Green and Gray All Interiors: White Only Shipping Weight1350 lbs shipped in Twelve(12) boxes Shipped via Motor Freight Pallet Dimensions 44″ x 86″ x 43″ Box Dimensions Box 1: 70″ Long x 20″ Wide x 8″ High Box 2: 70″ Long x 20″ Wide x 8″ High Box 3: 57″ Long x 13″ Wide x 6″ High Box 4: 70″ Long x 21″ Wide x 8″ High Box 5: 68″ Long x 21″ Wide x 8″ High Box 6: 57″ Long x 13″ Wide x 7″ High Box 7: 58″ Long x 14″ Wide x 7″ High Box 8: 52″ Long x 11″ Wide x 8″ High Box 9: 53″ Long x 10″ Wide x 6″ High Box 10: 53″ Long x 9″ Wide x 6″ High Box 11: 71″ Long x 17″ Wide x 8″ High Box 12: 87″ Long x 27″ Wide x 8″ High Main Cover UV Protected Fabric Backed Poly Material 10 0z. Weight. 22 Mil. Thick. Fire Retardant Standard Main Cover & Doors meet CPAI -84 Section 5 Anchors Twenty-Two (22) 36” Anchor with U-Bolts & Drive Rod Std. Stock Number 14x42x17-PB144217HGN, PB144217HGY Product Documentation the assembly manual Additional Product Accessories 1-5/8″ U-BOLT $5.00 Add to cart 36″ ANCHOR DRIVE ROD $12.00 Add to cart BUNGEE CORDS $2.00 Select options This product has multiple variants. The options may be chosen on the product page CABLE HOOK ANCHOR $15.00 Add to cart Concrete Anchor $1.99 Add to cart DESICCANT BAG $5.00 Add to cart FLOOR KITS FOR 12’X20′ $89.60 Add to cart FLOOR KITS FOR 12’X24′ $89.60 Add to cart Large Auger Anchor $15.00 Add to cart LRG ROLL-UP DOOR KIT $127.40 Add to cart SM ROLL-UP DOOR KIT $53.20 Add to cart SMALL AUGER ANCHOR $7.00 Add to cart
